    Coordinate Measuring Machine Services With Tri Axial Automatic Control

    Ask Lasest Price
    Brand Name : AUSKY
    Model Number : AMH650
    Certification : CE, ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, D/A, D/P, , MoneyGram, Western Union
    Supply Ability : 50 sets per month
    Delivery Time : 30 Work days
    • Product Details
    • Company Profile

    Coordinate Measuring Machine Services With Tri Axial Automatic Control

    Coordinate Measuring Machine Services With Tri Axial Automatic Control


    Lab 2.5d Coordinate Measuring Machine Optical Video Measurement Instrument


    1. Movement of Mechanism:

    This measuring instrument is provided with tri-axial automatic control and equipped with import precision Nidec patch grating system, Japan Panasonic servo high-efficiency motor system, Taiwan TBI screw rod, Taiwan HIWIN high-precision guide rail as well as professional measuring software for measurement.


    2. Merits with auto-measuring instrument:

    This instrument can avoid human error of the “Object Work Piece” as caused by manual measuring, and can as well avoid secondary damage caused to “Object Work Piece” by manual measuring, with ensured mass stability and criteria consistency of the object work piece. This instrument can enhance multi-fold the detecting efficiency in the production process, identify the defects and control over non-yields beforehand in production process, and can meanwhile help lower part of the costs spent on manual detection, and increase the timeliness of product delivery.


    Technical parameters


    Paramter and ModelAMH650AMH860AMH1210
    WorkbenchGlass table size(mm)808X5681008X6681300X1048
    Load-bearing weight(kg)303030
    TravelX axis(mm)5006001000
    Y axis(mm)6008001200
    Z axis(mm)200200200
    Image and measurement systemDisplay resolution(mm)1/0.5(Optional)
    Instrument precision(um)(4+L/200)um
    Imaging system(CCD)TEO HD color
    Zoom objective(X)High percision automatic zoom lens program control
    Total video magnification(x)30~190X
    Working distance(mm)96mm
    Light sourceLED programmable partiton light source(Coaxial light source optional)
    Outline dimension(mm)1500X1140X1781720X1240X17802090X1630X1800
    Weight(kg)1500kg1800kg2500kg
    Power supply220V AC 50Hz

    Configuration List:


    Sequence number

    Name

    Unit

    Quantity

    1

    Main body

    PCS

    1

    2

    Instrument table

    PCS

    1

    3

    AUSKY software

    PCS

    1

    4

    video card

    PCS

    1

    5

    Joystick

    PCS

    1

    6

    Dongle

    PCS

    1

    7

    Computer

    PCS

    1

    8

    Liquid crystal display

    PCS

    1

    9

    Aocheng optical calibration block

    PCS

    1

    10

    Precision probe(optional)

    PCS

    1

    11

    Keyboard and mouse

    PCS

    1

    12

    Specification warranty card certificate

    PCS

    1


    Introduction to the software functions:


    Software interface



    A. Multiple measuring methods, including auto edge-tracing, auto sectional edge-tracing, mouse on-screen point fetch, crossline pointing, proximity pointing, contrast and pinnacle pointing, contour pointing, probe pointing, laser pointing, and etc.



    B. Workpiece array macro
    Responding to circumstances of placing simultaneously multiple identical or different fixtures on workbench, array on
    each fixture can be identical or different. User can simply replace the fixture after measuring workpieces on one fixture,
    which help save time and increase efficiency.
    (Fixture 1) (Workpiece 1)



    B. Import CAD graphics for measuring


    The software supports measuring on workpieces with CAD graphics as template, which enable coordinate measuring or
    comparison measuring. Such function is applicable to workpiece of any contour/shape within gauging range of the
    measuring instrument.
